Cooling Mode | Air Cooling |
Discharge Pressure | 12 Bar |
Volume Flow (FAD) CFM | 45 |
Discharge Temperature | Ambient Temperature +15⁰C |
Noise Level | 72±2 dBA |
Driven Mode | Belt Driven |
Motor Capacity | 11KW / 15HP |
Power | Three Phase AC |
Voltage / Frequency | 415V /50Hz |
Starting Method | Star Delta Starter |
Isolation Grade | Class F |
Vent Pipe Diameter | G 1" |
Dimension (L x W x H) mm | |
Weight (Kgs) | 480 Kgs |
