Motor | |
---|---|
Category | L3 |
Motor Type | BLDC |
Max Speed | 25 kmph |
Rated Power | 1.5 kW 48V |
Peak Power | 2.0 kW 48V |
Range/Per Charge(kms) | 95* with 100Ah |
Gradient | 10 Deg |
Chassis | |
Suspension | Coil Spring |
Wheel size | 4.00 - 10 |
Brake System | Hydraulic Drum |
Seating | D+4 |
Dimensions (L*W*H) | |
Overall | 2820*1000*1790mm |
Ground Clearance | 170 |
Loading Capacity | 350 kgs |
Electrical | |
Speedometer | Digital |
Charger Volt & Time | 58.4 V & 3-4 hrs (Approx.) |
Battery Chemistry | LFP |
Controller Volt | 42-58 V |
Head light | LED |
